Red Smoke R9 9v Battery Stand-Alone Smoke Alarm

SKU: rer9

Red Smoke R9 9v Battery Stand-Alone Smoke Alarm

Inquire here

Model No: R9
A photoelectric, 9v battery smoke alarm.
Suitable for Installation in Caravan RV, Trailers and Motorhomes.
No wiring required for installation and includes a test/hush button and visual indicators.
The R9 smoke alarm is approved and certified to meet AS3786:2014.
Clipsal Has No Equivalent, Brooks Equivalent EIB650C,PSA Equivalent LIFPE9M

For Full Specifications Click on the Brochure Link Under The Main Image.

(rer9)

Red Smoke Alarms R9 Spec Sheet

Key Information
Product Brand	Red Smoke Alarms
Product or Component	Smoke Detector
Device Application	Early detection of smouldering fires and open fires
Electronic Sensor Type	Photo-electric sensor
Colour	White (RAL 9003)
Quantity per Set	Set of 1
Type of Packing	Carton
Battery Type	9V DC Carbon Zinc Battery
Battery Life	< 40mA at 9V
Operating Current	10 μA
Detection Type	Smoke
Function Available	Hush Function, Self-test of smoke detection, Local alarm
Control Type	Button for test/hush function
Response time	Approx. 8s
Noise Level	85 dB at 3m minimum
Time Delay Range	10 min for hush
Local Signal	Sound: Alarm, Sound: Signal, Visual: 1 LED (red) for warning and low battery
Type of Installation	Indoor
Device Mounting	Surface
Fixing Mode	By screws
Diameter	100 mm
Height	34 mm
Environment
Ambient Air Temperature for Operation	0...40°C
Relative Humidity	10...90%
Standards	AS 3786 : 2014/ amdt 2:2018
Disclaimer
The information provided in this table contains general descriptions and/or technical characteristics of the performance of the products contained herein. This table is not intended as a substitute for and is not to be used for determining suitability of reliability of these products for specific user applications. It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof. Neither Red Smoke Alarms PTY. LTD nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
